01 / SPECIFICATIONS
Technical specifications
| Filter medium | Modified PTFE |
|---|---|
| Support and hardware | PFA |
| Listed removal ratings | Semiconductor catalogue: 2 nm–0.5 μm |
| Maximum operating temperature | X1/X2/Z1/Z2/Z3 recommended below 120°C; disposable E4/E5 not above 180°C |
| Maximum operating pressure | Disposable 0.58 MPa @ 25°C; 0.097 MPa @ 180°C |
| Maximum forward differential pressure | Cartridge 0.49 MPa @ 25°C |
| Maximum reverse differential pressure | Cartridge 0.39 MPa @ 25°C |
| Filtration area | X1 0.91; X2 1.21; Z1 1.3; Z2/E4 2.2; Z3/E5 3.0 m² per 10″ |
02 / FEATURES
Key features
- Dry and UPW-prewet formats are listed.
03 / APPLICATIONS
Applications
Selection notes
- The separate CHR datasheet, pages 2 and 5, uses different configuration names and ratings starting at 5 nm. This page follows the semiconductor catalogue; confirm the current controlled specification when ordering.
